9 Comments on “How should you configure the implementation?”

1. movieman says:

   September 24, 2015 at 9:33 am

   Seattle Site 3 Data DeDuplication




   0




   0
2. correction says:

   September 28, 2015 at 3:58 am

   – Why Seattle/Site 3?
   – Why not Storage Spaces:
   https://technet.microsoft.com/en-us/library/jj822937.aspx

   Any better suggestions and explanations?




   0




   0
3. dumpsmcse says:

   October 6, 2015 at 4:03 am

   Seattle – Site 3 – DFS Replication

   * Scenario:
   The company needs a highly available file share cluster for a new Virtual Desktop Environment (VDE). It has the following requirements:
   – The file share cluster must withstand the loss of a single server.
   – The file share cluster must withstand the loss of a single network path.
   – The file share cluster must use the least amount of disk space.
   – The new file share cluster must have a highly available storage solution for a Hyper-V environment.
   – The new file share cluster must support guest VM clusters.
   – The storage cannot reside on any of the physical Hyper-V hosts.

   ———————————————————————————————————————————–
   All the servers in the Chicago office run Windows Server 2012. Any future servers that are deployed in the Chicago office must also run Windows Server 2012.
   ———————————————————————————————————————————–
   The Chicago office contains a primary data center and a backup data center. A Hyper-V cluster named Clusterl.contoso.com resides in the primary data center. The cluster has a multiple network path configured.
   ———————————————————————————————————————————–
   The backup data center for the Chicago office is located on a Hyper-V cluster named Cluster2.contoso.com. The cluster has a single network path configured.
   ———————————————————————————————————————————–

   +++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
   All servers in the Seattle office run Windows Server 2012 R2. Any future servers that are deployed in the Seattle office must also run Windows Server 2012 R2.
   +++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
   The Seattle office contains a primary data center and a backup data center. The primary data center is located on a Hyper-V cluster named Cluster3.contoso.com. The cluster has a multiple network path configured. +++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
   The backup data center for the Seattle office is located on a Hyper-V cluster named Cluster4.contoso.com. The cluster has a single network path configured.
   +++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

   Explanation:
   DFS Replication is an efficient, multiple-master replication engine that you can use to keep folders synchronized between servers across limited bandwidth network connections.
   DFS Replication uses a compression algorithm known as remote differential compression (RDC). RDC detects changes to the data in a file and enables DFS Replication to replicate only the changed file blocks instead of the entire file.
   https://msdn.microsoft.com/en-us/library/cc771058.aspx

   If you are considering implementing DFS replication, consider using Windows 2012 R2 because DFS replication has been massively improved. It supports larger data sets and performance has dramatically been improved over Windows 2008 R2.
   Note: windows 2012 R2 improves DFS replication dramatically, only more reason to upgrade your file servers to 2012 R2 or higher.
   http://louwrentius.com/my-experiences-with-dfs-replication-on-windows-2008-r2.html




   0




   0
   1. vader66 says:

      March 5, 2017 at 7:37 pm

      DFS is a replicate on close technology. The replication occurs when you click save or close. DFS meant for .doc, .pptx, .pdf ect not vhd or vhdx files.




      0




      0
4. jeff says:

   October 8, 2015 at 12:53 pm

   Agreed with (Seattle – Site 3)( for withstand the loss of a single server & single network path)

   the question said ‘The company needs a highly available file share cluster for a new Virtual Desktop Environment (VDE).’

   if you had HA file server cluster to storage guest VMs vhdx file. DFS and DDup is not best practice.

   the question is asked selection of ‘storage type’. I would go ‘Iscsi target block storage’




   0




   0
5. OSA says:

   October 30, 2015 at 1:57 am

   Seattle/Site 3/Storage Spaces.

   Requirement for storage “The new file share cluster must support guest VM clusters”
   To meet the requirement (shared vhdx), storage has to support SMB 3.02
   CSV on 2012 R2 meets the requirement.
   For CSV, storage spaces connected to 2012 R2 servers ( 2 or more servers in a cluster, with clustered SoF)

   http://blogs.technet.com/b/askpfeplat/archive/2015/06/01/how-shared-vhdx-works-on-server-2012-r2.aspx
   https://technet.microsoft.com/en-us/library/jj822937.aspx




   0




   0
6. JamesL says:

   December 5, 2015 at 3:34 pm

   Here is my two pennies worth(cents for our US friends :-))

   Agree with OSA Seattle/Site 3/Storage Spaces based on the following

   As the case study does not tell us which data centre is associated with which site I have made the following assumption
   Site1 = Primary Site Chicago – cluster1
   Site2 = Backup Site Chicago – cluster2
   Site3 = Primary Site Seattle – cluster3
   Site4 = Backup Site Seattle – cluster4

   – The file share cluster must withstand the loss of a single server.
   Dynamic Quorum ?? Available in 2012 and R2 so doesn’t help in selection choice
   https://technet.microsoft.com/en-GB/library/jj612870.aspx#BKMK_dynamic

   – The file share cluster must withstand the loss of a single network path.
   Based on my assumption. Can not be either of the backup Data Centres as they only have single network configurations therefore Site2 & Site4 do not meet requirements. Site 1 does not meet the 2012R2 requirements for shared vhdx in my next point therefore we are left with Site 3 as our answer

   – The file share cluster must use the least amount of disk space.
   Shared vhdx?? Must be 2012R2 therefore must be Seattle
   https://technet.microsoft.com/library/dn265980.aspx
   Deduplication will save space but IMO it is not a Storage Type (it is a feature)! Therefore not applicable. You can use dedup in 2012R2 SoFS but not 2012 SoFS so again Seattle becomes our choice. See “When to use Scale-Out File Server” in this link
   https://technet.microsoft.com/en-GB/library/hh831349.aspx

   – The new file share cluster must have a highly available storage solution for a Hyper-V environment.
   I think Storage Spaces is the option as it is a MS solution and they will want to push us in this direction for an answer
   http://www.thomasmaurer.ch/2013/08/hyper-v-over-smb-scale-out-file-server-and-storage-spaces/

   – The new file share cluster must support guest VM clusters.
   IMO Only applicable to the new virtualized SQL Server cluster named VM-SQLclusterl.contoso.com

   – The storage cannot reside on any of the physical Hyper-V hosts.
   IMO Only applicable to the new virtualized SQL Server cluster named VM-SQLclusterl.contoso.com




   0




   0
7. Jatin says:

   March 7, 2016 at 2:55 pm

   1. Data Center – Answer is Seattle ( it is running W2K12 with shared Disk capability with vhdx support, Can not be any backup DCs because they do not support Multipath Network)

   2. Site 2 – They are referring Seattle as Site 2

   3. Storage Type – Block Level Storage ( If you enable Guest Level Clustering ,You need to Provide Block Level Storage, In this scenario we need to setup VM-SQL-NOD1 and NODE2 as a guest cluster)https://technet.microsoft.com/en-GB/library/hh848272.aspx




   0




   0
8. RR says:

   August 29, 2016 at 10:11 am

   Guest Clustering needs block level storage (https://technet.microsoft.com/en-us/library/dn265980(v=ws.11).aspx)

   Can be Storage Spaces (JBOD) or iSCSI. I think MS wants you to use MPIO with iSCSI (no single network path)




   0
