You work as a network engineer for a Company. Study the exhibit carefully. In this network, R1 is
redistributing 10.1.5.0/24 into OSPF, and R2 is originating 10.1.4.0/24 as an internal route. R6 has
received packets destined to 10.1.4.1 and 10.1.5.1. Which statement is true about the path or
paths these two packets will take?

Based on the network provided in the exhibit, in these two areas, all routers are performing OSPF
on all interfaces. After examining the OSPF database on R4, do you know which type of LSA will
contain 10.1.5.0/24, and which router will have originated it?

On the basis of the exhibit provided, assuming that EIGRP is the routing protocol, then at R5, what
would be the status of each path to 172.30.1.0/24?

Based on the network provided in the exhibit, how to route the traffic arriving at R1 for 10.1.3.1?

On the basis of the network provided in the exhibit, R1 is injecting 10.1.5.0/24 by use of a network
statement as a network (type 2) LSA. What LSAs will R6 have in its local database for
10.1.5.0/24?

Which types of prefixes will a router running BGP most likely advertise to an IBGP peer, assuming
it is not configured as a route reflector?

Which mechanism can you use to achieve sub-second failover for link failure detection when a
switched Ethernet media is used and loss of signal is not supported by the link provider?

You have a router running BGP for the MPLS network and OSPF for the local LAN network at the
sales office. A route is being learned from the MPLS network that also exists on the OSPF local
network. It is important that the router chooses the local LAN route being learned from the
downstream switch running OSPF rather than the upstream BGP neighbor. Also, if the local OSPF
route goes away, the BGP route needs to be used. What should be configured to make sure that
the router will choose the LAN network as the preferred path?

In BGP routing, what does the rule of synchronization mean?

Router 1 is configured for BGP as dual-homed on the Cisco network. Which three BGP attributes
are carried in every BGP update on this router (both IBGP and EBGP)? (Choose three.)
