Based on the following show ip bgp neighbors output from Domain 2, which two statements are true? (Choose two)

Based on the following show ip bgp neighbors output from Domain 2, which two statements are true? (Choose two)

Domain 2#show ip bgp neighbors
BGP neighbor is 10.1.1.5, remote AS 65101, internal link Index 1, Offset 0, Mask 0x2
Route-Reflector Client
BGP version 4, remote router ID 5.5.5.5
BGP state = Established, table version = 4, up for
00:01:29
Last read 00:00:29, hold time is 180, keepalive interval is 60 seconds
Minimum time between advertisement runs is 5 seconds Received 13556 messages, 0 notifications, 0 in queue Sent 13454 messages, 0 notifications, 0 in queue Prefix advertised 0, suppressed 0, withdraw 0
Default weight 900
Inbound path policy configured
Route map for incoming advertisement is test
Connections established 31; dropped 30
Last reset 00:01:40, due to User reset
3 accepted prefixes consume 96 bytes
0 history paths consume 0 bytes
0 history paths consume 0 bytes

1 Status codes: s suppressed, d damped, h history, *valid,>best,iinternal Origin codes: i – IGP, e &#

Exhibit:
R1#show ip bgp
BGP table version is 1, local router ID is 10.0.0.1 Status codes: s suppressed, d damped, h history, *valid,>best,iinternal Origin codes: i – IGP, e – EGP,? – incomplete
Network Next Hop Metric LocPrf Wight Path
*i133.3.0.0 3.3.3.3 0 100 0 65101 i
*i172.0.0.0/8 20.1.1.5 0 100 0 65102 i
R1#show ip route
Codes: C – connected, S – static, I – IGRP, R -RIP, M -mobile, B
– BGP
D – EIGRP, EX – EIGRP external, O – OSPF, IA – OSPF inter area
N1 – OSPF NSSA external type 1, N2 – OSPF NSSA external type 2
E1 – OSPF external type 1, E2 – OSPF external type 2, E – EGP i – IS-IS, L1 – IS-IS level-1, L2 – IS-IS level-2, * – candidate default
U – per-user static route, o – ODR, P – periodic downloaded staticroute
T – traffic engineered route
Gateway of last resort is not set
C 30.0.0.0/8 is directly connected, FastEthernet0/0
C 10.0.0.0/8 is directly connected, Loopback111
C 40.0.0.0/8 is directly connected, Serial0/0
Based on the exhibits show ip bgp and show ip route output, what is the most likely problem that causes the two IBGP routes NOT to be selected as the best route in the BGP table?

1 neighbor to toggle between the Idle and Active state?

Based on the following show ip bgp neighbor 10.1.1.1 output:
R1#show ip bgp neighbors 10.1.1.1
BGP neighbor is 10.1.1.1, remote AS 65103, external link BGP version 4, remote under ID 0.0.0.0
BGP state = Active
Last read 00:00:04, hold time is 180, keepalive interval is 60 seconds
Received 44 messages, 0 notifications, 0 in queue Sent 45 messages, 6 notifications, 0 in queue
Route refresh request: received 0, sent 0
Default minimum time between advertisement runs in 30 seconds
For address family: IPv4 Unicast
BGP table version 1, neighbor version 0
Index 2, Offset 0, Mask 0x4
0 accepted prefixes consume 0 bytes
Prefix advertised 0, suppressed 0, withdraw 0
Number of NLRIs in the update sent: max 0, min 0 Connections established 7; dropped 7
Last reset 00:05:18, due to BGP Notification received, peer in wrong AS
External BGP neighbor may be up to 2 hops away.
No active TCP connection
What is causing the BGP session to the 10.1.1.1 neighbor to toggle between the Idle and Active state?

0/8 to Domain 4 via BGP? (Choose two) hostname Domain 1

Exhibit:

Which two configuration commands will complete the BGP configuration on Domain 1 so it will conditionally announce the 172.0.0.0/8 to Domain 4 via BGP? (Choose two) hostname Domain 1
!
!output omitted
!
1. _____________________
!
router bgp 65001
neighbor 172.16.1.1 remote-as 65001
neighbor 2.2.2.2 remote-as 65001
neighbor 4.4.4.4 remote-as 387
!
2. ____________________
!

What is step 2?

BGP table

Address Prefix AS-Path Next hop Communities Other attr.
10.0.0.0 /8 65100 65101 1.1.1.1 65101:111
… … … … … …

IP routing table
Protocol Address Prefix Next-hop Outgoing interface BGP 10.0.0.0 /8 1.1.1.1
OSPF 1.1.1.1 /32 172.16.1.2 Ethernet 0
conn. 172.16.1.0 /24 Ethernet 0

IP routing table

Protocol Address Prefix Next-hop Outgoing
interface
BGP 10.0.0.0 /8 1.1.1.1
OSPF 1.1.1.1 /32 172.16.1.2 Ethernet 0
conn. 172.16.1.0 /24 Ethernet 0

To forward a packet to 10.0.0.0/8, the router perform the following steps:
Step 1. Search the ip routing table for a route to reach the 10.0.0.0/8 network.
Step 2. ___________________________
Step 3. Find the connected outgoing interface to reach 172.16.1.2. Step 4. Arp for the 172.16.1.2 MAC address if it is not already in the ARP cache. Step 5. Store the 172.16.1.2 MAC address in the Fast Switching cache for successive packets to network 10.0.0.0.
What is step 2?
