A server named CA1 has the Active Directory Certificate Services server role installed and is configured as an
###BeginCaseStudy###
Case Study: 2
Proseware Inc
General Overview
Proseware Inc., is a manufacturing company that has 4,000 employees.
Proseware works with a trading partner named Fabrikam, Inc.
Physical Locations
Proseware has a main office and two branch office. The main office is located in London.
The branch offices are located in Madrid and Berlin. Proseware has a sales department based
in the London office and a research department based in the Berlin office.
The offices connect to each other by using a WAN link. Each office connects directly to the Internet.
Proseware rents space at a hosting company. All offices have a dedicated WAN link to the
hosting company. Web servers that are accessible from the Internet are located at the hosting company.
Active Directory
The Proseware network contains an Active Directory forest named proseware.com. The
forest contains a single domain. The forest functional level is Windows Server 2012.
Each office contains three domain controllers. An Active Directory site is configured for each office.
System state backups are performed every day on the domain controllers by using System
Center 2012 R2 Data Protection Manager (DPM).
Virtualization
Proseware has Hyper-V hosts that run Windows Server 2012 R2. Each Hyper-V host
manages eight to 10 the virtual machines. The Hyper-V hosts are configured as shown in the
following table.
All of the Hyper-V hosts store virtual machines on direct-attached storage (DAS).
Servers
All servers run Windows Server 2012 R2. All of the servers are virtualized, except for the
Hyper-V hosts.
VDI1 and VDI2 use locally attached storage to host virtual hard disk (VHD) files. The VHDs
use the .vhd format.
A line-of-business application named SalesApp is used by the sales department and runs on a
server named APP1. APP1 is hosted on HyperV2.
A server named CA1 has the Active Directory Certificate Services server role installed and is
configured as an enterprise root certification authority (CA) named ProsewareCA.
Ten load-balanced web servers hosted on HyperV7 and HyperVS run the Internet-facing web
site that takes orders from Internet customers.
System Center 2012 R2 Operations Manager is used to monitor the health of the servers on
the network.
All of the servers are members of the proseware.com domain, except for the servers located
in the perimeter network.
Client Computers
All client computers run either Windows 8.1 or Windows 1. Some of the users in the London
office connect to pooled virtual desktops hosted on VDI1 and VDI2.
Problem Statements
Proseware identifies the following issues on the network:
Virtualization administrators report that the load on the Hyper-V hosts is inconsistent. The
virtualization administrators also report that administrators fail to account for host utilization
when creating new virtual machines.
Users in the sales department report that they experience issues when they attempt to access
SalesApp from any other network than the one in the London office.
Sometimes, configuration changes are not duplicated properly across the web servers,
resulting in customer ordering issues. Web servers are regularly changed.
Demand for virtual desktops is increasing. Administrators report that storage space is
becoming an issue as they want to add more virtual machines.
In the past, some personally identifiable information (PII) was exposed when paper shredding
procedures were not followed.
Requirements
Planned Changes
Proseware plans to implement the following changes on the network:
• Implement a backup solution for Active Directory.
• Relocate the sales department to the Madrid office.
• Implement System Center 2012 R2 components, as required.
• Protect email attachments sent to Fabrikam that contain PII data so that the
attachments cannot be printed.
• Implement System Center 2012 R2 Virtual Machine Manager (VMM) to manage the
virtual machine infrastructure. Proseware does not plan to use private clouds in the
near future.
• Deploy a new Hyper-V host named RESEARCH1 to the Berlin office. RESEARCH1
will be financed by the research department. All of the virtual machines deployed to
RESEARCH1 will use VMM templates.
Technical Requirements
Proseware identifies the following virtualization requirements:
• The increased demand for virtual desktops must be met.
• Once System Center is deployed, all of the Hyper-V hosts must be managed by using
VMM.
• If any of the Hyper-V hosts exceeds a set number of virtual machines, an
administrator must be notified by email.
• Network administrators in each location must be responsible for managing the HyperV hosts in their respective location. The management of the hosts must be performed
by using VMM.
• The network technicians in each office must be able to create virtual machines in their
respective office. The network technicians must be prevented from modifying the host
server settings.
• New virtual machines must be deployed to RESEARCH1 only if the virtual machine
template used to create the machine has a value specified for a custom property
named CostCenter’ that matches Research’.
The web site configurations must be identical on all web servers.
Security Requirements
Proseware identifies the following security requirements:
• All email messages sent to and from Fabrikam must be encrypted by using digital
certificates issued to users by the respective CA of their company. No other
certificates must be trusted between the organizations.
• Microsoft Word documents attached to email messages sent from Proseware to
Fabrikam must be protected.
• Privileges must be minimized, whenever possible.
###EndCaseStudy###
You need to recommend changes to the existing environment to meet the PII requirement.
What should you recommend?
A server named CA1 has the Active Directory Certificate Services server role installed and is configured as an
###BeginCaseStudy###
Case Study: 2
Proseware Inc
General Overview
Proseware Inc., is a manufacturing company that has 4,000 employees.
Proseware works with a trading partner named Fabrikam, Inc.
Physical Locations
Proseware has a main office and two branch office. The main office is located in London.
The branch offices are located in Madrid and Berlin. Proseware has a sales department based
in the London office and a research department based in the Berlin office.
The offices connect to each other by using a WAN link. Each office connects directly to the Internet.
Proseware rents space at a hosting company. All offices have a dedicated WAN link to the
hosting company. Web servers that are accessible from the Internet are located at the hosting company.
Active Directory
The Proseware network contains an Active Directory forest named proseware.com. The
forest contains a single domain. The forest functional level is Windows Server 2012.
Each office contains three domain controllers. An Active Directory site is configured for each office.
System state backups are performed every day on the domain controllers by using System
Center 2012 R2 Data Protection Manager (DPM).
Virtualization
Proseware has Hyper-V hosts that run Windows Server 2012 R2. Each Hyper-V host
manages eight to 10 the virtual machines. The Hyper-V hosts are configured as shown in the
following table.
All of the Hyper-V hosts store virtual machines on direct-attached storage (DAS).
Servers
All servers run Windows Server 2012 R2. All of the servers are virtualized, except for the
Hyper-V hosts.
VDI1 and VDI2 use locally attached storage to host virtual hard disk (VHD) files. The VHDs
use the .vhd format.
A line-of-business application named SalesApp is used by the sales department and runs on a
server named APP1. APP1 is hosted on HyperV2.
A server named CA1 has the Active Directory Certificate Services server role installed and is
configured as an enterprise root certification authority (CA) named ProsewareCA.
Ten load-balanced web servers hosted on HyperV7 and HyperVS run the Internet-facing web
site that takes orders from Internet customers.
System Center 2012 R2 Operations Manager is used to monitor the health of the servers on
the network.
All of the servers are members of the proseware.com domain, except for the servers located
in the perimeter network.
Client Computers
All client computers run either Windows 8.1 or Windows 1. Some of the users in the London
office connect to pooled virtual desktops hosted on VDI1 and VDI2.
Problem Statements
Proseware identifies the following issues on the network:
Virtualization administrators report that the load on the Hyper-V hosts is inconsistent. The
virtualization administrators also report that administrators fail to account for host utilization
when creating new virtual machines.
Users in the sales department report that they experience issues when they attempt to access
SalesApp from any other network than the one in the London office.
Sometimes, configuration changes are not duplicated properly across the web servers,
resulting in customer ordering issues. Web servers are regularly changed.
Demand for virtual desktops is increasing. Administrators report that storage space is
becoming an issue as they want to add more virtual machines.
In the past, some personally identifiable information (PII) was exposed when paper shredding
procedures were not followed.
Requirements
Planned Changes
Proseware plans to implement the following changes on the network:
• Implement a backup solution for Active Directory.
• Relocate the sales department to the Madrid office.
• Implement System Center 2012 R2 components, as required.
• Protect email attachments sent to Fabrikam that contain PII data so that the
attachments cannot be printed.
• Implement System Center 2012 R2 Virtual Machine Manager (VMM) to manage the
virtual machine infrastructure. Proseware does not plan to use private clouds in the
near future.
• Deploy a new Hyper-V host named RESEARCH1 to the Berlin office. RESEARCH1
will be financed by the research department. All of the virtual machines deployed to
RESEARCH1 will use VMM templates.
Technical Requirements
Proseware identifies the following virtualization requirements:
• The increased demand for virtual desktops must be met.
• Once System Center is deployed, all of the Hyper-V hosts must be managed by using
VMM.
• If any of the Hyper-V hosts exceeds a set number of virtual machines, an
administrator must be notified by email.
• Network administrators in each location must be responsible for managing the HyperV hosts in their respective location. The management of the hosts must be performed
by using VMM.
• The network technicians in each office must be able to create virtual machines in their
respective office. The network technicians must be prevented from modifying the host
server settings.
• New virtual machines must be deployed to RESEARCH1 only if the virtual machine
template used to create the machine has a value specified for a custom property
named CostCenter’ that matches Research’.
The web site configurations must be identical on all web servers.
Security Requirements
Proseware identifies the following security requirements:
• All email messages sent to and from Fabrikam must be encrypted by using digital
certificates issued to users by the respective CA of their company. No other
certificates must be trusted between the organizations.
• Microsoft Word documents attached to email messages sent from Proseware to
Fabrikam must be protected.
• Privileges must be minimized, whenever possible.
###EndCaseStudy###
You need to ensure that RESEARCH1 only contains the required virtual machines.
What should you do?
A server named CA1 has the Active Directory Certificate Services server role installed and is configured as an
###BeginCaseStudy###
Case Study: 2
Proseware Inc
General Overview
Proseware Inc., is a manufacturing company that has 4,000 employees.
Proseware works with a trading partner named Fabrikam, Inc.
Physical Locations
Proseware has a main office and two branch office. The main office is located in London.
The branch offices are located in Madrid and Berlin. Proseware has a sales department based
in the London office and a research department based in the Berlin office.
The offices connect to each other by using a WAN link. Each office connects directly to the Internet.
Proseware rents space at a hosting company. All offices have a dedicated WAN link to the
hosting company. Web servers that are accessible from the Internet are located at the hosting company.
Active Directory
The Proseware network contains an Active Directory forest named proseware.com. The
forest contains a single domain. The forest functional level is Windows Server 2012.
Each office contains three domain controllers. An Active Directory site is configured for each office.
System state backups are performed every day on the domain controllers by using System
Center 2012 R2 Data Protection Manager (DPM).
Virtualization
Proseware has Hyper-V hosts that run Windows Server 2012 R2. Each Hyper-V host
manages eight to 10 the virtual machines. The Hyper-V hosts are configured as shown in the
following table.
All of the Hyper-V hosts store virtual machines on direct-attached storage (DAS).
Servers
All servers run Windows Server 2012 R2. All of the servers are virtualized, except for the
Hyper-V hosts.
VDI1 and VDI2 use locally attached storage to host virtual hard disk (VHD) files. The VHDs
use the .vhd format.
A line-of-business application named SalesApp is used by the sales department and runs on a
server named APP1. APP1 is hosted on HyperV2.
A server named CA1 has the Active Directory Certificate Services server role installed and is
configured as an enterprise root certification authority (CA) named ProsewareCA.
Ten load-balanced web servers hosted on HyperV7 and HyperVS run the Internet-facing web
site that takes orders from Internet customers.
System Center 2012 R2 Operations Manager is used to monitor the health of the servers on
the network.
All of the servers are members of the proseware.com domain, except for the servers located
in the perimeter network.
Client Computers
All client computers run either Windows 8.1 or Windows 1. Some of the users in the London
office connect to pooled virtual desktops hosted on VDI1 and VDI2.
Problem Statements
Proseware identifies the following issues on the network:
Virtualization administrators report that the load on the Hyper-V hosts is inconsistent. The
virtualization administrators also report that administrators fail to account for host utilization
when creating new virtual machines.
Users in the sales department report that they experience issues when they attempt to access
SalesApp from any other network than the one in the London office.
Sometimes, configuration changes are not duplicated properly across the web servers,
resulting in customer ordering issues. Web servers are regularly changed.
Demand for virtual desktops is increasing. Administrators report that storage space is
becoming an issue as they want to add more virtual machines.
In the past, some personally identifiable information (PII) was exposed when paper shredding
procedures were not followed.
Requirements
Planned Changes
Proseware plans to implement the following changes on the network:
• Implement a backup solution for Active Directory.
• Relocate the sales department to the Madrid office.
• Implement System Center 2012 R2 components, as required.
• Protect email attachments sent to Fabrikam that contain PII data so that the
attachments cannot be printed.
• Implement System Center 2012 R2 Virtual Machine Manager (VMM) to manage the
virtual machine infrastructure. Proseware does not plan to use private clouds in the
near future.
• Deploy a new Hyper-V host named RESEARCH1 to the Berlin office. RESEARCH1
will be financed by the research department. All of the virtual machines deployed to
RESEARCH1 will use VMM templates.
Technical Requirements
Proseware identifies the following virtualization requirements:
• The increased demand for virtual desktops must be met.
• Once System Center is deployed, all of the Hyper-V hosts must be managed by using
VMM.
• If any of the Hyper-V hosts exceeds a set number of virtual machines, an
administrator must be notified by email.
• Network administrators in each location must be responsible for managing the HyperV hosts in their respective location. The management of the hosts must be performed
by using VMM.
• The network technicians in each office must be able to create virtual machines in their
respective office. The network technicians must be prevented from modifying the host
server settings.
• New virtual machines must be deployed to RESEARCH1 only if the virtual machine
template used to create the machine has a value specified for a custom property
named CostCenter’ that matches Research’.
The web site configurations must be identical on all web servers.
Security Requirements
Proseware identifies the following security requirements:
• All email messages sent to and from Fabrikam must be encrypted by using digital
certificates issued to users by the respective CA of their company. No other
certificates must be trusted between the organizations.
• Microsoft Word documents attached to email messages sent from Proseware to
Fabrikam must be protected.
• Privileges must be minimized, whenever possible.
###EndCaseStudy###
You need to recommend changes to the existing environment to meet the email
requirement.
What should you recommend?
A server named CA1 has the Active Directory Certificate Services server role installed and is configured as an
###BeginCaseStudy###
Case Study: 2
Proseware Inc
General Overview
Proseware Inc., is a manufacturing company that has 4,000 employees.
Proseware works with a trading partner named Fabrikam, Inc.
Physical Locations
Proseware has a main office and two branch office. The main office is located in London.
The branch offices are located in Madrid and Berlin. Proseware has a sales department based
in the London office and a research department based in the Berlin office.
The offices connect to each other by using a WAN link. Each office connects directly to the Internet.
Proseware rents space at a hosting company. All offices have a dedicated WAN link to the
hosting company. Web servers that are accessible from the Internet are located at the hosting company.
Active Directory
The Proseware network contains an Active Directory forest named proseware.com. The
forest contains a single domain. The forest functional level is Windows Server 2012.
Each office contains three domain controllers. An Active Directory site is configured for each office.
System state backups are performed every day on the domain controllers by using System
Center 2012 R2 Data Protection Manager (DPM).
Virtualization
Proseware has Hyper-V hosts that run Windows Server 2012 R2. Each Hyper-V host
manages eight to 10 the virtual machines. The Hyper-V hosts are configured as shown in the
following table.
All of the Hyper-V hosts store virtual machines on direct-attached storage (DAS).
Servers
All servers run Windows Server 2012 R2. All of the servers are virtualized, except for the
Hyper-V hosts.
VDI1 and VDI2 use locally attached storage to host virtual hard disk (VHD) files. The VHDs
use the .vhd format.
A line-of-business application named SalesApp is used by the sales department and runs on a
server named APP1. APP1 is hosted on HyperV2.
A server named CA1 has the Active Directory Certificate Services server role installed and is
configured as an enterprise root certification authority (CA) named ProsewareCA.
Ten load-balanced web servers hosted on HyperV7 and HyperVS run the Internet-facing web
site that takes orders from Internet customers.
System Center 2012 R2 Operations Manager is used to monitor the health of the servers on
the network.
All of the servers are members of the proseware.com domain, except for the servers located
in the perimeter network.
Client Computers
All client computers run either Windows 8.1 or Windows 1. Some of the users in the London
office connect to pooled virtual desktops hosted on VDI1 and VDI2.
Problem Statements
Proseware identifies the following issues on the network:
Virtualization administrators report that the load on the Hyper-V hosts is inconsistent. The
virtualization administrators also report that administrators fail to account for host utilization
when creating new virtual machines.
Users in the sales department report that they experience issues when they attempt to access
SalesApp from any other network than the one in the London office.
Sometimes, configuration changes are not duplicated properly across the web servers,
resulting in customer ordering issues. Web servers are regularly changed.
Demand for virtual desktops is increasing. Administrators report that storage space is
becoming an issue as they want to add more virtual machines.
In the past, some personally identifiable information (PII) was exposed when paper shredding
procedures were not followed.
Requirements
Planned Changes
Proseware plans to implement the following changes on the network:
• Implement a backup solution for Active Directory.
• Relocate the sales department to the Madrid office.
• Implement System Center 2012 R2 components, as required.
• Protect email attachments sent to Fabrikam that contain PII data so that the
attachments cannot be printed.
• Implement System Center 2012 R2 Virtual Machine Manager (VMM) to manage the
virtual machine infrastructure. Proseware does not plan to use private clouds in the
near future.
• Deploy a new Hyper-V host named RESEARCH1 to the Berlin office. RESEARCH1
will be financed by the research department. All of the virtual machines deployed to
RESEARCH1 will use VMM templates.
Technical Requirements
Proseware identifies the following virtualization requirements:
• The increased demand for virtual desktops must be met.
• Once System Center is deployed, all of the Hyper-V hosts must be managed by using
VMM.
• If any of the Hyper-V hosts exceeds a set number of virtual machines, an
administrator must be notified by email.
• Network administrators in each location must be responsible for managing the HyperV hosts in their respective location. The management of the hosts must be performed
by using VMM.
• The network technicians in each office must be able to create virtual machines in their
respective office. The network technicians must be prevented from modifying the host
server settings.
• New virtual machines must be deployed to RESEARCH1 only if the virtual machine
template used to create the machine has a value specified for a custom property
named CostCenter’ that matches Research’.
The web site configurations must be identical on all web servers.
Security Requirements
Proseware identifies the following security requirements:
• All email messages sent to and from Fabrikam must be encrypted by using digital
certificates issued to users by the respective CA of their company. No other
certificates must be trusted between the organizations.
• Microsoft Word documents attached to email messages sent from Proseware to
Fabrikam must be protected.
• Privileges must be minimized, whenever possible.
###EndCaseStudy###
You need to implement a solution for the email attachments.
Both organizations exchange root CA certificates and install the certificates in the relevant
stores.
You duplicate the Enrollment Agent certificate template and generate a certificate based on
the new template.
Which additional two actions should you perform? Each correct answer presents part of the
solution.
Where should you recommend performing each task?
HOTSPOT
###BeginCaseStudy###
Case Study: 3
Northwind Traders
Overview
Northwind Traders is an IT services and hosting provider.
Northwind Traders has two main data centers in North America. The data centers are located
in the same city. The data centers connect to each other by using high-bandwidth, low-latency
WAN links. Each data center connects directly to the Internet.
Northwind Traders also has a remote office in Asia that connects to both of the North
American data centers by using a WAN link. The Asian office has 30 multipurpose servers.
Each North American data center contains two separate network segments. One network
segment is used to host the internal servers of Northwind Traders. The other network segment
is used for the hosted customer environments.
Existing Environment
Active Directory
The network contains an Active Directory forest named northwindtraders.com. The forest
contains a single domain. All servers run Windows Server 2012 R2.
Server Environment
The network has the following technologies deployed:
• Service Provider Foundation
• Windows Azure Pack for Windows Server
• System Center 2012 R2 Virtual Machine Manager (VMM)
• An Active Directory Rights Management Services (AD RMS) cluster
• An Active Directory Certificate Services (AD CS) enterprise certification authority
(CA)
All newly deployed servers will include the following components:
• Dual 10-GbE Remote Direct Memory Access (RDMA)-capable network adapters
• Dual 1-GbE network adapters
• 128 GB of RAM
Requirements
Business Goals
Northwind Traders will provide hosting services to two customers named Custoner1 and
Customer2, network of each customer is configured as shown in the following table.
Planned Changes
Northwind Traders plans to implement the following changes:
• Deploy System Center 2012 R2 Operations Manager.
• Deploy Windows Server 2012 R2 iSCSI and SMB-based storage.
• Implement Hyper-V Recovery Manager to protect virtual machines.
• Deploy a certificate revocation list (CRL) distribution point (CDP) on the internal
network.
• For Customer 1, install server authentication certificates issued by the CA of
Northwind Traders on the virtual machine in the hosting networks.
General Requirements
Northwind Traders identifies the following requirements:
• Storage traffic must use dedicated adapters.
• All storage and network traffic must be load balanced.
• The amount of network traffic between the internal network and the hosting network
must be minimized.
• The publication of CRLs to CDPs must be automatic.
• Each customer must use dedicated Hyper-V hosts.
• Administrative effort must be minimized, whenever possible.
• All servers and networks must be monitored by using Operations Manager.
• Anonymous access to internal file shares from the hosting network must be
prohibited.
• All Hyper-V hosts must use Cluster Shared Volume (CSV) shared storage to host
virtual machines.
• All Hyper-V storage and network traffic must remain available if single network
adapter fails.
• The Hyper-V hosts connected to the SMB-based storage must be able to use of the
RDMA technology.
• The number of servers and ports in the hosting environment to which the customer
has access must be minimized.
Customer1 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use SMB-based storage exclusively.
• Customer1 must use App Controller to manage hosted virtual machines.
• The virtual machines of Customer1 must be recoverable if a single data center fails.
• Customer1 must be able to delegate self-service roles in its hosted environment to its
users.
• Customer1 must be able to check for the revocation of certificates issued by the CA of
Northwind Traders.
• The users of Customer1 must be able to obtain use licenses for documents protected
by the AD RMS of Northwind Traders.
• Certificates issued to the virtual machines of Customer1 that reside on the hosted
networks must be renewed automatically.
Customer2 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use iSCSI-based storage exclusively.
• All of the virtual machines of Customer2 must be migrated by using a SAN transfer.
• None of the metadata from the virtual machines of Customer1 must be stored in
Windows Azure.
• The network configuration of the Hyper-V hosts for Customer2 must be controlled by
using logical switches.
• The only VMM network port profiles and classifications allowed by Customer2 must
be low-bandwidth, medium-bandwidth, or high-bandwidth.
• The users at Northwind Traders must be able to obtain use licenses for documents
protected by the AD RMS cluster of Customer2. Customer2 plans to decommission
its AD RMS cluster during the next year.
###EndCaseStudy###
You need to recommend changes to allow Customer! to delegate permissions in its hosting
environment to its users.
Where should you recommend performing each task? To answer, select the appropriate
location for each task in the answer area.
Which actions should you recommend performing for each customer?
HOTSPOT
###BeginCaseStudy###
Case Study: 3
Northwind Traders
Overview
Northwind Traders is an IT services and hosting provider.
Northwind Traders has two main data centers in North America. The data centers are located
in the same city. The data centers connect to each other by using high-bandwidth, low-latency
WAN links. Each data center connects directly to the Internet.
Northwind Traders also has a remote office in Asia that connects to both of the North
American data centers by using a WAN link. The Asian office has 30 multipurpose servers.
Each North American data center contains two separate network segments. One network
segment is used to host the internal servers of Northwind Traders. The other network segment
is used for the hosted customer environments.
Existing Environment
Active Directory
The network contains an Active Directory forest named northwindtraders.com. The forest
contains a single domain. All servers run Windows Server 2012 R2.
Server Environment
The network has the following technologies deployed:
• Service Provider Foundation
• Windows Azure Pack for Windows Server
• System Center 2012 R2 Virtual Machine Manager (VMM)
• An Active Directory Rights Management Services (AD RMS) cluster
• An Active Directory Certificate Services (AD CS) enterprise certification authority
(CA)
All newly deployed servers will include the following components:
• Dual 10-GbE Remote Direct Memory Access (RDMA)-capable network adapters
• Dual 1-GbE network adapters
• 128 GB of RAM
Requirements
Business Goals
Northwind Traders will provide hosting services to two customers named Custoner1 and
Customer2, network of each customer is configured as shown in the following table.
Planned Changes
Northwind Traders plans to implement the following changes:
• Deploy System Center 2012 R2 Operations Manager.
• Deploy Windows Server 2012 R2 iSCSI and SMB-based storage.
• Implement Hyper-V Recovery Manager to protect virtual machines.
• Deploy a certificate revocation list (CRL) distribution point (CDP) on the internal
network.
• For Customer 1, install server authentication certificates issued by the CA of
Northwind Traders on the virtual machine in the hosting networks.
General Requirements
Northwind Traders identifies the following requirements:
• Storage traffic must use dedicated adapters.
• All storage and network traffic must be load balanced.
• The amount of network traffic between the internal network and the hosting network
must be minimized.
• The publication of CRLs to CDPs must be automatic.
• Each customer must use dedicated Hyper-V hosts.
• Administrative effort must be minimized, whenever possible.
• All servers and networks must be monitored by using Operations Manager.
• Anonymous access to internal file shares from the hosting network must be
prohibited.
• All Hyper-V hosts must use Cluster Shared Volume (CSV) shared storage to host
virtual machines.
• All Hyper-V storage and network traffic must remain available if single network
adapter fails.
• The Hyper-V hosts connected to the SMB-based storage must be able to use of the
RDMA technology.
• The number of servers and ports in the hosting environment to which the customer
has access must be minimized.
Customer1 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use SMB-based storage exclusively.
• Customer1 must use App Controller to manage hosted virtual machines.
• The virtual machines of Customer1 must be recoverable if a single data center fails.
• Customer1 must be able to delegate self-service roles in its hosted environment to its
users.
• Customer1 must be able to check for the revocation of certificates issued by the CA of
Northwind Traders.
• The users of Customer1 must be able to obtain use licenses for documents protected
by the AD RMS of Northwind Traders.
• Certificates issued to the virtual machines of Customer1 that reside on the hosted
networks must be renewed automatically.
Customer2 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use iSCSI-based storage exclusively.
• All of the virtual machines of Customer2 must be migrated by using a SAN transfer.
• None of the metadata from the virtual machines of Customer1 must be stored in
Windows Azure.
• The network configuration of the Hyper-V hosts for Customer2 must be controlled by
using logical switches.
• The only VMM network port profiles and classifications allowed by Customer2 must
be low-bandwidth, medium-bandwidth, or high-bandwidth.
• The users at Northwind Traders must be able to obtain use licenses for documents
protected by the AD RMS cluster of Customer2. Customer2 plans to decommission
its AD RMS cluster during the next year.
###EndCaseStudy###
You need to recommend a solution that meets the AD RMS requirements of Customer1 and Customer2.
Which actions should you recommend performing for each customer? To answer, select the
appropriate customer for each action in the answer area.
What is the best approach to achieve the goal?
###BeginCaseStudy###
Case Study: 3
Northwind Traders
Overview
Northwind Traders is an IT services and hosting provider.
Northwind Traders has two main data centers in North America. The data centers are located
in the same city. The data centers connect to each other by using high-bandwidth, low-latency
WAN links. Each data center connects directly to the Internet.
Northwind Traders also has a remote office in Asia that connects to both of the North
American data centers by using a WAN link. The Asian office has 30 multipurpose servers.
Each North American data center contains two separate network segments. One network
segment is used to host the internal servers of Northwind Traders. The other network segment
is used for the hosted customer environments.
Existing Environment
Active Directory
The network contains an Active Directory forest named northwindtraders.com. The forest
contains a single domain. All servers run Windows Server 2012 R2.
Server Environment
The network has the following technologies deployed:
• Service Provider Foundation
• Windows Azure Pack for Windows Server
• System Center 2012 R2 Virtual Machine Manager (VMM)
• An Active Directory Rights Management Services (AD RMS) cluster
• An Active Directory Certificate Services (AD CS) enterprise certification authority
(CA)
All newly deployed servers will include the following components:
• Dual 10-GbE Remote Direct Memory Access (RDMA)-capable network adapters
• Dual 1-GbE network adapters
• 128 GB of RAM
Requirements
Business Goals
Northwind Traders will provide hosting services to two customers named Custoner1 and
Customer2, network of each customer is configured as shown in the following table.
Planned Changes
Northwind Traders plans to implement the following changes:
• Deploy System Center 2012 R2 Operations Manager.
• Deploy Windows Server 2012 R2 iSCSI and SMB-based storage.
• Implement Hyper-V Recovery Manager to protect virtual machines.
• Deploy a certificate revocation list (CRL) distribution point (CDP) on the internal
network.
• For Customer 1, install server authentication certificates issued by the CA of
Northwind Traders on the virtual machine in the hosting networks.
General Requirements
Northwind Traders identifies the following requirements:
• Storage traffic must use dedicated adapters.
• All storage and network traffic must be load balanced.
• The amount of network traffic between the internal network and the hosting network
must be minimized.
• The publication of CRLs to CDPs must be automatic.
• Each customer must use dedicated Hyper-V hosts.
• Administrative effort must be minimized, whenever possible.
• All servers and networks must be monitored by using Operations Manager.
• Anonymous access to internal file shares from the hosting network must be
prohibited.
• All Hyper-V hosts must use Cluster Shared Volume (CSV) shared storage to host
virtual machines.
• All Hyper-V storage and network traffic must remain available if single network
adapter fails.
• The Hyper-V hosts connected to the SMB-based storage must be able to use of the
RDMA technology.
• The number of servers and ports in the hosting environment to which the customer
has access must be minimized.
Customer1 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use SMB-based storage exclusively.
• Customer1 must use App Controller to manage hosted virtual machines.
• The virtual machines of Customer1 must be recoverable if a single data center fails.
• Customer1 must be able to delegate self-service roles in its hosted environment to its
users.
• Customer1 must be able to check for the revocation of certificates issued by the CA of
Northwind Traders.
• The users of Customer1 must be able to obtain use licenses for documents protected
by the AD RMS of Northwind Traders.
• Certificates issued to the virtual machines of Customer1 that reside on the hosted
networks must be renewed automatically.
Customer2 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use iSCSI-based storage exclusively.
• All of the virtual machines of Customer2 must be migrated by using a SAN transfer.
• None of the metadata from the virtual machines of Customer1 must be stored in
Windows Azure.
• The network configuration of the Hyper-V hosts for Customer2 must be controlled by
using logical switches.
• The only VMM network port profiles and classifications allowed by Customer2 must
be low-bandwidth, medium-bandwidth, or high-bandwidth.
• The users at Northwind Traders must be able to obtain use licenses for documents
protected by the AD RMS cluster of Customer2. Customer2 plans to decommission
its AD RMS cluster during the next year.
###EndCaseStudy###
You need to recommend a monitoring solution for Northwind Traders.
What is the best approach to achieve the goal? More than one answer choice may achieve
the goal. Select the BEST answer.
Which two role services should you identify?
###BeginCaseStudy###
Case Study: 3
Northwind Traders
Overview
Northwind Traders is an IT services and hosting provider.
Northwind Traders has two main data centers in North America. The data centers are located
in the same city. The data centers connect to each other by using high-bandwidth, low-latency
WAN links. Each data center connects directly to the Internet.
Northwind Traders also has a remote office in Asia that connects to both of the North
American data centers by using a WAN link. The Asian office has 30 multipurpose servers.
Each North American data center contains two separate network segments. One network
segment is used to host the internal servers of Northwind Traders. The other network segment
is used for the hosted customer environments.
Existing Environment
Active Directory
The network contains an Active Directory forest named northwindtraders.com. The forest
contains a single domain. All servers run Windows Server 2012 R2.
Server Environment
The network has the following technologies deployed:
• Service Provider Foundation
• Windows Azure Pack for Windows Server
• System Center 2012 R2 Virtual Machine Manager (VMM)
• An Active Directory Rights Management Services (AD RMS) cluster
• An Active Directory Certificate Services (AD CS) enterprise certification authority
(CA)
All newly deployed servers will include the following components:
• Dual 10-GbE Remote Direct Memory Access (RDMA)-capable network adapters
• Dual 1-GbE network adapters
• 128 GB of RAM
Requirements
Business Goals
Northwind Traders will provide hosting services to two customers named Custoner1 and
Customer2, network of each customer is configured as shown in the following table.
Planned Changes
Northwind Traders plans to implement the following changes:
• Deploy System Center 2012 R2 Operations Manager.
• Deploy Windows Server 2012 R2 iSCSI and SMB-based storage.
• Implement Hyper-V Recovery Manager to protect virtual machines.
• Deploy a certificate revocation list (CRL) distribution point (CDP) on the internal
network.
• For Customer 1, install server authentication certificates issued by the CA of
Northwind Traders on the virtual machine in the hosting networks.
General Requirements
Northwind Traders identifies the following requirements:
• Storage traffic must use dedicated adapters.
• All storage and network traffic must be load balanced.
• The amount of network traffic between the internal network and the hosting network
must be minimized.
• The publication of CRLs to CDPs must be automatic.
• Each customer must use dedicated Hyper-V hosts.
• Administrative effort must be minimized, whenever possible.
• All servers and networks must be monitored by using Operations Manager.
• Anonymous access to internal file shares from the hosting network must be
prohibited.
• All Hyper-V hosts must use Cluster Shared Volume (CSV) shared storage to host
virtual machines.
• All Hyper-V storage and network traffic must remain available if single network
adapter fails.
• The Hyper-V hosts connected to the SMB-based storage must be able to use of the
RDMA technology.
• The number of servers and ports in the hosting environment to which the customer
has access must be minimized.
Customer1 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use SMB-based storage exclusively.
• Customer1 must use App Controller to manage hosted virtual machines.
• The virtual machines of Customer1 must be recoverable if a single data center fails.
• Customer1 must be able to delegate self-service roles in its hosted environment to its
users.
• Customer1 must be able to check for the revocation of certificates issued by the CA of
Northwind Traders.
• The users of Customer1 must be able to obtain use licenses for documents protected
by the AD RMS of Northwind Traders.
• Certificates issued to the virtual machines of Customer1 that reside on the hosted
networks must be renewed automatically.
Customer2 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use iSCSI-based storage exclusively.
• All of the virtual machines of Customer2 must be migrated by using a SAN transfer.
• None of the metadata from the virtual machines of Customer1 must be stored in
Windows Azure.
• The network configuration of the Hyper-V hosts for Customer2 must be controlled by
using logical switches.
• The only VMM network port profiles and classifications allowed by Customer2 must
be low-bandwidth, medium-bandwidth, or high-bandwidth.
• The users at Northwind Traders must be able to obtain use licenses for documents
protected by the AD RMS cluster of Customer2. Customer2 plans to decommission
its AD RMS cluster during the next year.
###EndCaseStudy###
You plan to implement a solution that meets the certificate requirements of Customer1. You
need to identify which role services must be deployed to the hosting environment.
Which two role services should you identify? Each correct answer presents part of the solution.
Which three actions should you perform in sequence?
DRAG DROP
###BeginCaseStudy###
Case Study: 3
Northwind Traders
Overview
Northwind Traders is an IT services and hosting provider.
Northwind Traders has two main data centers in North America. The data centers are located
in the same city. The data centers connect to each other by using high-bandwidth, low-latency
WAN links. Each data center connects directly to the Internet.
Northwind Traders also has a remote office in Asia that connects to both of the North
American data centers by using a WAN link. The Asian office has 30 multipurpose servers.
Each North American data center contains two separate network segments. One network
segment is used to host the internal servers of Northwind Traders. The other network segment
is used for the hosted customer environments.
Existing Environment
Active Directory
The network contains an Active Directory forest named northwindtraders.com. The forest
contains a single domain. All servers run Windows Server 2012 R2.
Server Environment
The network has the following technologies deployed:
• Service Provider Foundation
• Windows Azure Pack for Windows Server
• System Center 2012 R2 Virtual Machine Manager (VMM)
• An Active Directory Rights Management Services (AD RMS) cluster
• An Active Directory Certificate Services (AD CS) enterprise certification authority
(CA)
All newly deployed servers will include the following components:
• Dual 10-GbE Remote Direct Memory Access (RDMA)-capable network adapters
• Dual 1-GbE network adapters
• 128 GB of RAM
Requirements
Business Goals
Northwind Traders will provide hosting services to two customers named Custoner1 and
Customer2, network of each customer is configured as shown in the following table.
Planned Changes
Northwind Traders plans to implement the following changes:
• Deploy System Center 2012 R2 Operations Manager.
• Deploy Windows Server 2012 R2 iSCSI and SMB-based storage.
• Implement Hyper-V Recovery Manager to protect virtual machines.
• Deploy a certificate revocation list (CRL) distribution point (CDP) on the internal
network.
• For Customer 1, install server authentication certificates issued by the CA of
Northwind Traders on the virtual machine in the hosting networks.
General Requirements
Northwind Traders identifies the following requirements:
• Storage traffic must use dedicated adapters.
• All storage and network traffic must be load balanced.
• The amount of network traffic between the internal network and the hosting network
must be minimized.
• The publication of CRLs to CDPs must be automatic.
• Each customer must use dedicated Hyper-V hosts.
• Administrative effort must be minimized, whenever possible.
• All servers and networks must be monitored by using Operations Manager.
• Anonymous access to internal file shares from the hosting network must be
prohibited.
• All Hyper-V hosts must use Cluster Shared Volume (CSV) shared storage to host
virtual machines.
• All Hyper-V storage and network traffic must remain available if single network
adapter fails.
• The Hyper-V hosts connected to the SMB-based storage must be able to use of the
RDMA technology.
• The number of servers and ports in the hosting environment to which the customer
has access must be minimized.
Customer1 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use SMB-based storage exclusively.
• Customer1 must use App Controller to manage hosted virtual machines.
• The virtual machines of Customer1 must be recoverable if a single data center fails.
• Customer1 must be able to delegate self-service roles in its hosted environment to its
users.
• Customer1 must be able to check for the revocation of certificates issued by the CA of
Northwind Traders.
• The users of Customer1 must be able to obtain use licenses for documents protected
by the AD RMS of Northwind Traders.
• Certificates issued to the virtual machines of Customer1 that reside on the hosted
networks must be renewed automatically.
Customer2 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use iSCSI-based storage exclusively.
• All of the virtual machines of Customer2 must be migrated by using a SAN transfer.
• None of the metadata from the virtual machines of Customer1 must be stored in
Windows Azure.
• The network configuration of the Hyper-V hosts for Customer2 must be controlled by
using logical switches.
• The only VMM network port profiles and classifications allowed by Customer2 must
be low-bandwidth, medium-bandwidth, or high-bandwidth.
• The users at Northwind Traders must be able to obtain use licenses for documents
protected by the AD RMS cluster of Customer2. Customer2 plans to decommission
its AD RMS cluster during the next year.
###EndCaseStudy###
You need to prepare for the migration of virtual machines across the Hyper-V hosts of Customer2.
Which three actions should you perform in sequence? To answer, move the appropriate
actions from the list of actions to the answer area and arrange them in the correct order.
which network adapter should you recommend performing each configuration?
HOTSPOT
###BeginCaseStudy###
Case Study: 3
Northwind Traders
Overview
Northwind Traders is an IT services and hosting provider.
Northwind Traders has two main data centers in North America. The data centers are located
in the same city. The data centers connect to each other by using high-bandwidth, low-latency
WAN links. Each data center connects directly to the Internet.
Northwind Traders also has a remote office in Asia that connects to both of the North
American data centers by using a WAN link. The Asian office has 30 multipurpose servers.
Each North American data center contains two separate network segments. One network
segment is used to host the internal servers of Northwind Traders. The other network segment
is used for the hosted customer environments.
Existing Environment
Active Directory
The network contains an Active Directory forest named northwindtraders.com. The forest
contains a single domain. All servers run Windows Server 2012 R2.
Server Environment
The network has the following technologies deployed:
• Service Provider Foundation
• Windows Azure Pack for Windows Server
• System Center 2012 R2 Virtual Machine Manager (VMM)
• An Active Directory Rights Management Services (AD RMS) cluster
• An Active Directory Certificate Services (AD CS) enterprise certification authority
(CA)
All newly deployed servers will include the following components:
• Dual 10-GbE Remote Direct Memory Access (RDMA)-capable network adapters
• Dual 1-GbE network adapters
• 128 GB of RAM
Requirements
Business Goals
Northwind Traders will provide hosting services to two customers named Custoner1 and
Customer2, network of each customer is configured as shown in the following table.
Planned Changes
Northwind Traders plans to implement the following changes:
• Deploy System Center 2012 R2 Operations Manager.
• Deploy Windows Server 2012 R2 iSCSI and SMB-based storage.
• Implement Hyper-V Recovery Manager to protect virtual machines.
• Deploy a certificate revocation list (CRL) distribution point (CDP) on the internal
network.
• For Customer 1, install server authentication certificates issued by the CA of
Northwind Traders on the virtual machine in the hosting networks.
General Requirements
Northwind Traders identifies the following requirements:
• Storage traffic must use dedicated adapters.
• All storage and network traffic must be load balanced.
• The amount of network traffic between the internal network and the hosting network
must be minimized.
• The publication of CRLs to CDPs must be automatic.
• Each customer must use dedicated Hyper-V hosts.
• Administrative effort must be minimized, whenever possible.
• All servers and networks must be monitored by using Operations Manager.
• Anonymous access to internal file shares from the hosting network must be
prohibited.
• All Hyper-V hosts must use Cluster Shared Volume (CSV) shared storage to host
virtual machines.
• All Hyper-V storage and network traffic must remain available if single network
adapter fails.
• The Hyper-V hosts connected to the SMB-based storage must be able to use of the
RDMA technology.
• The number of servers and ports in the hosting environment to which the customer
has access must be minimized.
Customer1 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use SMB-based storage exclusively.
• Customer1 must use App Controller to manage hosted virtual machines.
• The virtual machines of Customer1 must be recoverable if a single data center fails.
• Customer1 must be able to delegate self-service roles in its hosted environment to its
users.
• Customer1 must be able to check for the revocation of certificates issued by the CA of
Northwind Traders.
• The users of Customer1 must be able to obtain use licenses for documents protected
by the AD RMS of Northwind Traders.
• Certificates issued to the virtual machines of Customer1 that reside on the hosted
networks must be renewed automatically.
Customer2 Requirements
Northwind Traders identifies the following requirements for Customer1:
• Customer1 must use iSCSI-based storage exclusively.
• All of the virtual machines of Customer2 must be migrated by using a SAN transfer.
• None of the metadata from the virtual machines of Customer1 must be stored in
Windows Azure.
• The network configuration of the Hyper-V hosts for Customer2 must be controlled by
using logical switches.
• The only VMM network port profiles and classifications allowed by Customer2 must
be low-bandwidth, medium-bandwidth, or high-bandwidth.
• The users at Northwind Traders must be able to obtain use licenses for documents
protected by the AD RMS cluster of Customer2. Customer2 plans to decommission
its AD RMS cluster during the next year.
###EndCaseStudy###
You need to recommend a network configuration for the newly deployed Hyper-V hosts used
by Customer1.
On which network adapter should you recommend performing each configuration? To
answer, select the appropriate network adapter for each configuration in the answer area.
